Neo4j + GraphRAG in Action: Live Refactor

Jennifer Reif from Neo4j joined me to live-refactor Quanta, a file search app, from PostgreSQL to Neo4j. The idea was to replace flat vector similarity search with GraphRAG: model files, embeddings, and their relationships as a native graph for richer AI retrieval. Stack: Quarkus, LangChain4j's KnowledgeGraphWriter, Neo4j.

It did not work. Two hours in, no functional result. But the failure was more instructive than a clean demo would have been.

Co-Speaker

Jennifer Reif

Developer Advocate at Neo4j

Jennifer joined the session to help migrate the Quanta project from PostgreSQL to Neo4j and integrate GraphRAG via LangChain4j, bringing deep Neo4j expertise to the refactor.

GitHubX

What Is GraphRAG?

Standard RAG retrieves the most similar text chunks and passes them to the LLM. GraphRAG adds structure: it retrieves nodes and their relationships from a knowledge graph, so the LLM understands not just that two things are similar but why they are connected. For a file search app that means context shaped like your actual data, not a flat ranked list.

LangChain4j's KnowledgeGraphWriter writes entities and relationships into Neo4j during ingestion and hooks into the retrieval pipeline at query time.

100%−+

How the Session Went

Dependency alignment between Neo4j OGM, the Quarkus Neo4j extension, and LangChain4j consumed the first stretch before any meaningful code was written. After modeling entities and wiring the KnowledgeGraphWriter, the ingestion ran. Testing at 1:02:30 then surfaced failures in how embeddings were stored and retrieved. The rest of the session was a loop of remodeling, re-embedding, and rerunning. At 2:09:30 we were still fighting startup failures. Honest conclusion: didn't get there.

Four Lessons

1. GraphRAG Is Not Plug-and-Play Yet

The concept is clear; the tooling is narrow. LangChain4j's Neo4j surface area is still limited and documentation leaves real gaps. What looks obvious in a diagram (write entities, link relationships, query the graph) becomes a chain of version conflicts and undocumented edge cases in practice. Go in with more preparation time than you expect.

2. OGM Was the Wrong Abstraction

Neo4j OGM maps Java objects to graph nodes. It is useful in many contexts, but it was the wrong fit here. LangChain4j's KnowledgeGraphWriter operates at the Cypher level with plain string values and does not compose with OGM. Skipping OGM and working closer to raw Cypher from the start would have removed a major source of friction. It would be genuinely useful if the KnowledgeGraph tooling eventually extended to support OGM-style abstractions and if the documentation became clearer about which integration styles are actually supported.

3. Align on the Concept Before Writing Code

Two minutes of introduction, then straight into code. That was too fast. The KnowledgeGraphWriter graph model was never fully shared between us before the session began. Different mental models of the same problem turn every technical decision into friction. A five-minute diagram first would have aligned us and likely surfaced the OGM issue much earlier.

4. Projects Need Documentation, Not On-the-Fly Onboarding

Quanta is small, but small does not mean self-explanatory. Explaining the project structure while simultaneously refactoring it means neither gets proper attention. Jennifer brought strong Neo4j expertise. What was missing was a clear, upfront picture of what Quanta does, how it is layered, and what I wanted to change. A short written overview would have paid back immediately.

Useful Links

• Neo4j + LangChain4j GraphRAG blog post
• LangChain4j Neo4j embedding store docs (KnowledgeGraphWriter)
• Neo4j OGM manual
• Session code: Quanta, branch Add-Tags-and-Relations-with-neo4j
• Jennifers Podcast: Break Time Tech Talks

Final Thought

GraphRAG is a good idea and Neo4j is a natural fit for it. The tooling just isn't frictionless yet, and that gap only shows up when you try it on a real project. This session was an honest look at where that gap currently is.
